Hydraulic Single Head 4Kw Pipe End Forming Machine

    Buy cheap Hydraulic Single Head 4Kw Pipe End Forming Machine from wholesalers

    Buy cheap Hydraulic Single Head 4Kw Pipe End Forming Machine from wholesalers
    • Buy cheap Hydraulic Single Head 4Kw Pipe End Forming Machine from wholesalers

    Hydraulic Single Head 4Kw Pipe End Forming Machine

    Ask Lasest Price
    Model Number : TM40
    Supply Ability : 100set/Per Year
    Payment Terms : L/C, T/T
    Brand Name : CAOS
    Price : Negotiation
    Certification : ISO9001, CE
    • Product Details
    • Company Profile

    Hydraulic Single Head 4Kw Pipe End Forming Machine

    Hydraulic single head automatic pipe end forming machine

    Advantage for the hydraulic single head automatic pipe end forming machine
    A kind of high efficiency, full-auto machine
    Tube clamping and end forming driven by hydraulic
    Available end forming: oncave-convex section, long, flat, square, enlargement, slanting, V-shaped, open slot and others
    Good mechanical parts ensure machine runs in high stability.
    Simple die change process.
    CE, ISO9001 Certification

    Specification of the Hydraulic single head automatic pipe end forming machine

    Name
    UnitTM-40
    Max. End Forming CapacityMm40*2
    Max. End Forming Lengthmm100
    Reduction timemm/s100/3-4
    Max. Hydraulic PressureMpa12
    Motor PowerKw4
    Dimension of machinemm2400*650*1350
    Weight of the machinekg1100


    Configuration of the Hydraulic single head automatic pipe end forming machine

    NAME
    Supplier
    Hydraulic MotorWuxi Taihu
    Hydraulic ValveJapan Yuken
    Over-flow ValveJapan Yuken
    Adjustable ValveJapan Yuken
    Sealing ElementTaiwan Ding Zing
    PLCJapan Omron
    Touch ScreenTaiwan Weinview
    ContactorCHNT
    Over-Thermal RelayCHNT
    TransformerCHNT
    FuseCHNT
    Proximity SwitchTaiwan YANGMING
    Oil TubeTaiwan Lianhui
    Quality Hydraulic Single Head 4Kw Pipe End Forming Machine for sale
